Steam Engine Vertical Structure Model Q1

This engine  is a Vertical structure, Model Q1, length55MM, width 32MM, high 78MM. Weight 238G. Bores 10MM, piston stroke 12MM, flywheel diameter 26MM. Output shaft 5MM.Screw fitting is 1/4 "X 40 TPI. Pressure(in psi) is it designed to run at (about 10-50psi) ,Pipeline appropriate 3MM or 4MM.

Its structure is quite compact, made of metal carefully made of brass and stainless steel. Base increase the performance of two stainless steel bearings enhanced engine.Use stainless steel hex screws, engine seems more retro.

This is one of a series of Q steam engines, I hope you'll like it, maybe you'll collection Q series models all models.

Our goal is to offer quality products to our customer. We carry completed models and continue to expand our engine types. Please feel free to ask questions. We will do our best to answer in a timely manner.We appreciate your business and look forward to serving you!

Sincerely,

Jin

Delivery Time is approx. 8-18 business days to most US / UK / AU destinations.
